Smart Gateway - XA-GW411S
Smart Gateway
XA-GW411S
Router + AC + PoE Combo
Distributed AP Networking
Standalone Installation
Template Configuration
1× Gigabit WAN Port + 4× Gigabit LAN Ports
Seamless Roaming
IEEE 802.3at Protocol
IPTV Passthrough
60W Power Supply
Security Firewall
Supports Max Bandwidth 1000Mbps
Cloud Platform Management
Manages up to 128 APs
Remote Management
Max Concurrent Users 128
| Part Number | XA-GW411S |
| CPU | MT7621DAT |
| Flash + RAM | 16MB+128MB |
| Interface | 1×1000Mbps(RJ45) LAN, 4×1000Mbps(RJ45) |
| PoE standard | IEEE 802.3af (15.4W), IEEE 802.3at (30W) |
| Button | 1× Reset button |
| Power | 52V 1.2A, Total PoE Output: 54W (max) |
| Power Consumption | 8W (Non-PoE) |
| Dimensions | 122mm×90mm×27.3mm |
