Switch - XA-SWG108-P
Switch
XA-SWG108-P
Complies with IEEE 802.3af/at standards, automatically identifies powered devices (PDs), and delivers safe power supply
Supports port short-circuit protection and overload protection
Provides 8×10/100/1000Mbps PoE ports+2×10/100/1000Mbps RJ45 uplink ports
Full metal casing with efficient heat dissipation
Total power: 120W; maximum output power per port: 30W
Plug and play, zero configuration
Supports 4KV surge protection
| Part Number | XA-SWG108-P |
| PoE Standard | IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3az (Half-Duplex, Full-Duplex) |
| Fixed Ports | 8×10/100/1000Mbps PoE ports with 52V PoE power supply, compliant with IEEE 802.3af/at, max. 30W per port 2×10/100/1000Mbps RJ45 uplink ports |
| PoE | Adaptive power output supports IEEE 802.3af (15.4W) and IEEE 802.3at (30W) Power pinout: 1/2+ 3/6- |
| Backplane Bandwidth | 12Gbps |
| Power Consumption | Total power consumption (without PoE load) < 5W |
| Power Supply | Input voltage: AC 100~240V, Maximum total output power: 120W |
| Dimensions | 220mm×162mm×43.2mm (bare unit) |
